2-Way Valve Changeover - Checking Functions

[Manual Operation of Valve]
  1. Turn off power breaker at the back of the control panel.
  2. Run 0.4MPa ~ 0.5MPa of dry compressed air to the air kit of the valve.
  3. Press the Manual button on the valve (orange button).

TOP VIEW OF THE 2-WAY VALVE
With the Manual button pressed, solenoid valve will be on and the 2-way valve will diverge towards the No. 2 direction.
With Manual button not pressed, solenoid valve will be off and 2-way valve will switch over towards the No. 1 direction.
